QZ SERIES

QZ SERIES

Feature

■Comprehensive GNSS support, including GPS Modernization signals, QZSS,GLONASS, BeiDou and Galileo
■Precision satellite tracking without grandplane.
■Compact and lightweight [a type]
■Our own counterplan of multipath [b type]
■Waterproof(JIS C 0920 IP67)
■Japanese LTE filtering
■RoHS

Supported satellite list

※You can browse PDF by clicking the product name.

Products GPS/QZSS
(L6:QZS only)
GLONASS Galileo BeiDou
L1 L2 L5 L6 G1 G2 E1 E5a E6 B1
QZG1a
QZG12a
QZ15a
QZ16a
QZG126c
QZG126d(In development)

With Q connector you can fit quickly

QSMA connector

Our QSMA(SMA compatible) connector is adopted as the connector part of the QZ series.That can quick fitting with Push-on Full lock mechanism . In addition, IP66 · IP 67 application at the time of merging complete waterproofing is realized.

Cables

Product name Connector A Connector B Cable Length
QSMA-WP-SMA-WP-1.5D-L3m QSAM(P) SMA(P) 1.5D 3m
QTNC-WP-TNC-WP-1.5D-L3m QTNC(P) TNC(P) 1.5D 3m

The above is an example. We accept assembly by various connectors and cables

Mount conversion screw

For compact and lightweight a Type, it is assumed to be multiple used in a wide range of applications, and 1/4 unified screw used for camera tripod etc. is adopted for mounting. More precise b Type adopts 5/8 which is often used for surveying instruments. Conversion adapter of each screw is also being prepared.
